Scintillation Screens

Advatech can supply a broad range of specialist scintillation screens based on the following crystals: GAGG(Ce), LuAG(Ce), YAG(Ce) and YAP(Ce).

Scintillation Screens - Materials

The following summarises the range of scintillation screens currently available:

• GAGG(Ce)
• LuAG(Ce)
• LuAP(Ce)
• YAG(Ce)
• YAP(Ce)

Scintillation Screens - Sizes/Mounting

The above materials are typically supplied in the following formats:

• Standard Screens: Up to 50mm in diameter and in thicknesses from a few mm down to 100um.
• Thins Screens: Up to 20mm in diameter and in thicknesses down to 20 - 50um.
• Edge Mounted Screens: Up to 10mm in diameter, bonded to a metal ring, and down to 20um in thickness
• Substrate Mounted Screens: Up to 25mm in diameter, bonded to a substrate (e.g. quartz) and down to 5um in thickness

Scintillation Screens - Coatings

The above screens can be provided with various surfaces coatings.
