Radiation Probes - CZT
The following range of CZT radiation probe variants is available. Each probe contains a CZT quasi-hemispherical sensor coupled with a matched, low noise preamplifier. All are robustly housed and come complete with a cable and connector.
CZT Probe Variants
| Part Number | Detector Volume (mm³) |
Probe Size (mm) |
Conversion Efficiency (mV/keV) |
Bias Voltage (V) |
Energy Resolution FWHM@662keV (keV) |
Peak-to-Compton Ratio @662keV |
|---|---|---|---|---|---|---|
| RIT-310/Z/01 | c.1.2 | 8.2Ø x 90 | > 0.1 | < 600 | ≤ 20 | ≤ 1.3 |
| RIT-310/Z/05 | c.5 | 8.2Ø x 90 | > 0.1 | < 600 | ≤ 22 | ≤ 1.6 |
| RIT-310/Z/05S | c.5 | 8.2Ø x 90 | > 0.1 | < 600 | ≤ 10 | ≤ 2.5 |
| RIT-310/Z/20 | c.15 | 8.2Ø x 90 | > 0.1 | < 600 | ≤ 22 | ≤ 1.6 |
| RIT-310/Z/20S | c.15 | 8.2Ø x 90 | > 0.1 | < 600 | ≤ 10 | ≤ 2.5 |
| RIT-310/Z/60 | c.55 | 8.2Ø x 90 | > 0.1 | < 600 | ≤ 25 | ≤ 1.8 |
| RIT-310/Z/60S | c.55 | 8.2Ø x 90 | > 0.1 | < 600 | ≤ 15 | ≤ 2.5 |
| RIT-311 | 0.5 .. 20 | 45 x 24 x 4 | > 0.1 | < 600 | 10 - 22 | ≤ 2.5 |
| RIT-311/C* | 0.5 .. 200 | 45 x 24 x 4 | > 0.1 | < 600 | N/A | N/A |
| RIT-313 | 1 .. 10 | 6Ø x 63 | > 0.1 | < 500 | <22 | ≤ 2.5 |
| RIT-500S | 500 | 24Ø x 58 | > 0.2 | < 1,500 | <2.5 | >4.0 |
| RIT-1500 | 1500 | 32Ø x 58 | > 0.2 | < 2,500 | <3.5 | >4.0 |
| RIT-4000 | 4000 | 40Ø x 58 | > 0.1 | < 3,000 | <4.0 | >4.0 |
| DT-01A | TBA | 17Ø x 79 | TBA | < 500 | <6.5% @ 59.5keV | TBA |
| DT-02A | TBA | 30.5Ø x 67 | TBA | TBA | <6.5% @ 59.5keV | TBA |
